PNL 36-13
Bus Divider Switchgear With Load Break Switch (Exit From Side)
Used to disconnect and divide main circuit.
Standard Equipment
- SF6 Isolated Load Break Switch
- Earthing Switch (Type 1)
- Capacitive Voltage Indicator
- Switch Mechanism
- Through Passage Isolator
- Opening / Closing Coils
- Auxiliary Contacts
- Main Bus Bars
- Heater with Thermostatic Control
- Enclosure Earthing Bus Bars
Optional Equipment
- Load Break Switch Spring Winding Motor
Technical Drawings
